Battery

• 80V 1395Ah x 3 (40 cells - 2V per cell)
• On board battery charger with UL/CSA certified plug

           - 80V 125A x 3

• Centralized battery filling system with visual floater indicating battery fluid level
• Typical battery recharging time:  Approximately 8 hrs with 480V power source

Cabin and Driver Seat

• Steel cabin with side doors; driver and passenger seat.
• Adjustable driver seat with safety belt
• Cabin heater with temperature control dial

Rail & Rode Mode Performances

• Motor - 50kW x 2 - 80V - AC Brushless motors
• Hydraulic power steering type on front wheels / pump motor
• Suspension front and rear with semi-elliptic 4” wide leaf springs
• Front and rear heavy duty railway axle with hydraulic pump motor 3kW

On-board Transformer & Chargers

• On-board charger for each battery; eliminates need for free-standing charger installations.

Safety Devices

• Equipped with red and white directional movement signaling lights during rail mode
• Horn
• Orange beacon light
• Exterior emergency stop buttons
• Hand brake activation in case of low oil pressure in the braking system
• Emergency braking system in case of failure
• Safety system to prevent sudden direction change during operation
• Safety system to prevent unit from switching on during recharge

Machine Brakes

Road & Rail Mode

• Fully proportional hydraulic powerbrake system
• Parking/Emergency brake mechanical type with negative acting antagonist spring, working on an independent disc assembled on the transmission.

Train Air Brake System

• Pneumatic braking system with a 54 CFM compressor with electric motor

Lift Points

• Equipped with four RUD lifting eyes for transport. Each changes color when exposed to excessive stresses.

Instrument Panel

• Digital full-color touch screen display

Couplers

• Heavy-duty, spring-loaded, AAR type couplers with remote release; front and rear

Lighting

• LED headlights, tail lights, step lights and work lights
